Since the memory for ASH is limited, the data is only available for a few days or even hours. It is also usually gone when the instance was restarted, therefore, every 10 seconds a snapshot of the ASH data is stored permanently on disk and can be accessed through the view dba_hist_active_sess_history (DASH). The live view (Top activity) of Enterprise Manager is based on ASH data, AWR reports are based on dba_hist_* views.

To fully leverage all the information that the ASH provides, it helps to know some other useful views related to performance analysis.

All ASH/DASH data is stored at the CDB level and can be accessed either from the CDB or a specific PDB. However, when you want to map the USER_ID, CURRENT_OBJ#, CURRENT_FILE# etc to names stored in dba_views, it’s best to query ASH from within the corresponding PDB.

A word about gv$active_session_history vs. v$active_session_history: While they are defacto the same on a non-RAC database, on a RAC database the v$ variant only shows sessions running on one instance, whereas gv$ shows all sessions an all instances of the database. I therefore made it a habbit to always use gv$active_session_history and include the inst_id in my queries. The same is true for many other v$ views, in RAC there’s usually a gv$ variant (like gv$session).

Note that the dba_hist views are always cluster wide and store the data for all instances.

ASH and DASH have over 100 fields, and more are added with each release. The description of all fields is available here: https://docs.oracle.com/en/database/oracle/oracle-database/19/refrn/DBA_HIST_ACTIVE_SESS_HISTORY.html

All fields of ASH/DASH can be useful in specific cases, but the following are the most commonly used:

Good to Know:

• Wait events that only affect the CDB, such as backup activities, are not shown when querying ASH in the PDB.
• A session in the PDB can have a blocking session from the CDB, e.g., the logwriter session. The wait events of the blocking session itself must then be analyzed via the CDB.

Before analyzing a problem in the ASH, you should ensure that the data for the relevant period is still available:

select oldest_sample_time from gv$ash_info;

-- output

OLDEST_SAMPLE_TIME
-------------------------------
03-SEP-21 03.34.03.575000000 AM

Query information before “OLDEST_SAMPLE_TIME” can only be viewed via DASH.

If you want to analyze the problem later, it is advisable to save the entire ASH to a table to not lose the data in it.

create table ash_snapshot as select * from gv$active_session_history;

In scripts, you should then select from this table instead:

-- from gv$active_session_history
from ash_snapshot

Good to Know: Queries that are no longer in ASH and ran less than 10 seconds may not appear in DASH either. In such cases, the waits of a query can no longer be meaningfully analyzed.

As you will shortly see, it’s very easy to start with a basic script to get an overview and then drill deeper to find the root cause of a particular problem. Even when you use scripts like Tanel Poder’s “ashtop” it’s good to have a basic understanding of how to query the ASH and get the maximum out of those scripts. I’ll also show the difference between queries from ASH or DASH.

Let’s start with a basic query which will be the blueprint for our more complex queries. It returns the most important columns of all wait events in the last hour for all nodes of a RAC database and works in both CDB and PDB.

Important: The “TIME_WAITED” column shows 0 for as long as the session was waiting for that particular event to end. When ordered by sample_time, the first non-zero value for a unique combination of inst_id/session_id/sql_id shows the total amount of time (in ms) the session had to wait on that event. When the “TIME_WAITED” and “EVENT” column are NULL (not 0), the session was on the CPU and not waiting for an event. You can select the session_state in your query if you want to confirm this.

set lines 400
set pages 100
column sample_time format a22 tru
column event format a30 tru

select sample_time, inst_id, sql_id, session_id, user_id, event, time_waited, current_obj#, blocking_session
from gv$active_session_history
where sample_time between sysdate-1/24 and sysdate
order by sample_time;

Difference from the ASH version:

• instance_number instead of inst_id
• dba_hist_active_sess_history instead of gv$active_session_history

set lines 400
set pages 100
column sample_time format a22 tru
column event format a30 tru

select sample_time, instance_number, sql_id, session_id, user_id, event, time_waited, current_obj#, blocking_session
from dba_hist_active_sess_history
where sample_time between sysdate-1/24 and sysdate
order by sample_time;

Sample Output:

The user and object names can be joined to have names instead of ids, but only in the PDB:

set lines 400
set pages 100
column sample_time format a22 tru
column event format a30 tru
column object_name format a30

select sample_time, inst_id, sql_id, session_id, b.username, event, time_waited, c.object_name, blocking_session
from gv$active_session_history a
join dba_users b on a.user_id = b.user_id
join dba_objects c on a.current_obj# = c.object_id
where sample_time between sysdate-1/24 and sysdate
order by 1;

Sample Output:

Now we are getting somewhere, we see the username and which objects where affected by the wait clearly.

The “sample_time” column can be used to limit the query period, allowing you to focus on the relevant part. This can be done relative to sysdate:

where sample_time between sysdate-1/24 and sysdate

or as a specific time range:

where sample_time between to_date('25-Nov-2020 00:40:00', 'DD-Mon-YYYY HH24:MI:SS')
and to_date('25-Nov-2020 00:50:00', 'DD-Mon-YYYY HH24:MI:SS')

or both combined:

where sample_time between to_date('25-Nov-2020 00:40:00', 'DD-Mon-YYYY HH24:MI:SS')
and sysdate;

In one hour, ASH can record a huge number of rows, but often only the last 100 are of interest. To focus only on them, reverse the sort order and limit the output with fetch:

where sample_time between sysdate-1/24 and sysdate
order by sample_time desc
fetch next 100 rows only

With the basic script, you can get an overview of what was happening in the database during the selected period. The script can then be extended as needed to further narrow down the problem.

If, for example, a blocking_session is responsible for many waits, you can look at this session in more detail — the number in the “blocking_session” column is the session_id of the blocking session:

where sample_time between sysdate-1/24 and sysdate
and session_id = 123456

Similarly, if you want to look at a specific query, just filter by sql_id:

where sample_time between sysdate-1/24 and sysdate
and sql_id = '1ps650r41s7qr'

In Oracle Enterprise Manager, you often only see the SQL_ID of the PL/SQL procedure among the top sessions. If you want to view all associated queries, filter by top_level_sql_id and specify the PL/SQL sql_id:

where sample_time between sysdate-1/24 and sysdate
and top_level_sql_id = '1ps650r41s7qr'

You can easily identify sessions affected by a specific wait using the Event column. A list of all possible wait events can be obtained with this query:

select name, wait_class FROM V$EVENT_NAME ORDER BY name;

Alternatively, you can list only the waits that actually occur in ASH:

select distinct event from gv$active_session_history order by 1;

To filter for specific event types, extend the basic query, for example:

where sample_time between sysdate-1/24 and sysdate
-- pick one of these:
-- index contention
and event = 'enq: TX - index contention'
-- all transaction contentions
and event like 'enq: TX%'
-- read/write operations
and (event like 'db file%' or event like 'direct path%')
-- all cluster waits (full RAC)
and event like 'gc%'

• Waits over 1 second:

and time_waited > 1000000

• Sessions accessing a specific object:

and c.object_name = 'NAME_OF_OBJECT'

• Sessions accessing a specific file:

and current_file# = 134

• Sessions accessing the same block in the same file (e.g., in case of contention):

and current_file# = 134
and current_block# = 123456

Some other ASH queries which are not directly developed from the basic script above but can also be useful.

With this query, you can check how much PGA each session_id has used:

select inst_id, session_id, session_serial#, max(pga_allocated)/1024/1024/1024 GB
from gv$active_session_history
where sample_time between sysdate-1/24 and sysdate
group by inst_id,session_id, session_serial#
order by 4;

Similarly, you can find the sessions that have used the most TEMP:

select inst_id, session_id, session_serial#, max(temp_space_allocated)/1024/1024/1024 GB
from gv$active_session_history
where sample_time between sysdate-1/24 and sysdate
group by inst_id, session_id, session_serial#
order by 4;

Now that we know how to query the ASH it’s time to speak about what to do with the information.

This is the true bread and butter of the ASH. Understanding wait events, why they occur, what impact they have, how to correlate them and ultimately how to solve them is what makes performance tuning an art form rather than a scientific method. I can not go into the details of every important wait event because most would warrant a dedicated blog post of it’s own. However, the official Oracle documentation has a brief description of all wait events:

https://docs.oracle.com/en/database/oracle/oracle-database/19/refrn/descriptions-of-wait-events.html

A good way to start when someone tells you that the database was slow, without any particulars like a sql_id or session_id, is to look for any events with a time_waited higher than a second. If one wait event stands out, check the documentation or google it. AI like perplexity.ai are also very good at explaining certain wait events, but it helps if you have at least some understanding because especially with everything Oracle, AI tends to blatantly lie to your face (apparently because the Oracle documentation is unclear, as perplexity explained to me :D).

When searching for wait events, it’s often useful to select the “P1” column (and possibly P2, P3). These provide additional information about the wait event, e.g. for Row Cache Locks, which DC Cache was involved. The columns “P1TEXT” (and P2TEXT, P3TEXT) give a descriptive name to the value. To see what the individual P-values mean, you can look at v$event_name:

set lines 400
col parameter1 format a20
col parameter2 format a20
col parameter3 format a20
select name, parameter1, parameter2, parameter3 FROM V$EVENT_NAME where name like 'row%lock' order by name;

Sample Output:

You can then extend the basic query accordingly:

set lines 400
set pages 100
column sample_time format a22 tru
column event format a30 tru

select sample_time, inst_id, sql_id, session_id, user_id, event, p1text, p1, time_waited
from gv$active_session_history
where sample_time between sysdate-1/24 and sysdate
and event like 'row%lock'
order by 1;

One of the most common reason for a sudden performance loss is the application itself accessing the database. This can have a very stupidsimple cause, like someone manually executed a query that was updating a column of all rows in a table while the application was running, resulting in tons of row locks.

Other less obvious causes are normal application sessions running slower than usual, causing locks and blocking other sessions. Possible causes from my own experience:

• execution plan of a query has suddenly changed for whatever reason, like missing statistics or different bind values
• a network problem between the application and DB server
• a network problem in a dataguard environment with MaxProtection between primary and standby
• accessing the same table on different instances in a RAC database, causing a lot of block shipping
• not enough SGA to handle increased application volume, resulting in more blocks read from disk
• not enough PGA to handle complex queries, resulting in more temp usage
• Oracle changing the default for the parameter db_lost_write_protection in 19.26c (this caused us real headache)
• and many more

Not all of these issues can be resolved with ASH alone but you most likely will find out where to look. For example, if you see a blocking session appearing in many other sessions, check what that session was doing:

• what queries was it running
• what objects was it accessing
• what wait events did it spend the most time on
• was it also blocked by yet another session

The examples in the drill down section above should help you closing in on the source of the problem.

This is an attempt of a cookie-cutter guide for some of the more common wait events.

Now that you hopefully have a better understanding of how to work with the active session history, it’s time to let you in on a secret: Tanel Poder’s script “ashtop.sql” does all the heavy lifting for us and in most cases it is no longer needed to write a custom script ourselfs. The basic script in this post can replaced with this ashtop.sql query:

@ashtop inst_id,session_id,sql_id,user,objt,event2,time_waited,blocking_session 1=1 sysdate-1/24 sysdate;

Or to just get an overview of the top queries:

@ashtop sql_id,event2 1=1 sysdate-1/24 sysdate;

Bear in mind though that it only shows the top 15 queries, which makes it even more important that you know what to query and be as specific as you can.

I am a big fan of ashtop.sql and use it on a daily basis. I explain it in detail with more drill down examples here: /oracle/ashtop
